產品特點 | Feature
n Three dimensional force sensor
n Senior alloy steel
n Easy to install
n Height of low rogidity
n Suitable for industrial weighing systems, overload protection on robot heads, testing machine. etc
l 三維力傳感器
l 優質合金鋼材質
l 安裝簡便
l 高度低 剛性好
l 適用于工業稱重系統，機器人手過載保護測式設備等
l 量程 | Capacities
l X:25/50N,Y：25/50N,Z:50/100N
l 客戶可以根據自己需求定制量程。
技術參數 | Specification
|
Rated Output |
額定輸出 |
1.0mv/v±1% |
|
Zero Balance |
零點平衡 |
±1% of rated output |
|
Creep After 30 Minutes |
蠕變 |
±0.2% of rated output |
|
Nonlinearity |
非線性 |
±0.5% of rated output |
|
Hysteresis |
滯后 |
±0.5% of rated output |
|
Repeatability |
重復性 |
±0.2% of rated output |
|
Temp. effect on output |
靈敏度溫漂 |
≤0.05% of applied output/℃ |
|
Temp. Effect on zero |
零點溫漂 |
≤0.05% of rated output/℃ |
|
Safe temp. Range |
可用溫度范圍 |
-10℃ to+70℃ |
|
Temp.Compensated |
溫度補償范圍 |
-10℃ to+40℃ |
|
Safe Overload |
安全載荷 |
150% |
|
Input Impedance |
輸入阻抗 |
700 Ω±10Ω |
|
Output Impedance |
輸出阻抗 |
700 Ω±10Ω |
|
Insulation Resistance |
絕緣阻抗 |
≥5000MΩ(50V DC) |
|
Rated Excitation |
推薦激勵電壓 |
10V DC/AC |
|
Protection Class |
防護等級 |
IP67 |
|
Construction |
電線 |
0-15t(3m)35-100t(12m) |
|
type |
型號說明 |
?型號+‚量程+ƒ非標功能F(無非標則不需填寫) 如：CL-TR4/35X50Y100Z |
|
Cable Color Code |
導線顏色 |
EXC:Blue(+E) Black(+E) XSIG:Gray(+S) YSIG:Brown(+S) Yellow(-S) ZSIG:White(+S) Red(-S) |
注：資料僅供參考，具體以實際訂貨為準。
